RISKWARE BETRAYER
WHO IS THE BIGGEST ONE?
YURY CHEMERKIN
MULTI-SKILLED SECURITY EXPERT

INTRO: RISKY MOBILE APPS
 Mobile applications store data locally and transfer it over networks (at least)
 Data - not only binary protected or non-protected. Quality of protection matters
 Reverse engineering gives an answer how it works and is protected (slowly)
 Pentesting the data protection gives an answer ‘what happened’ and ‘why’ (faster)
 Developers never tell and never admit they fail but they does
 Privacy Policy might be pure, high detailed or misleading even
 One app might be risky and has a quite bad data protection – OK
 One risky app over several dozens apps is a betrayer that lead to leaks – not OK

OWASP MOBILE PAST vs. NOW
 Top 10 Mobile Risks 2012-2013
 M1: Insecure Data Storage
 M2: Weak Server Side Controls
 M3: Insufficient Transport Layer Protection
 M4: Client Side Injection
 M5: Poor Authorization and Authentication
 M6: Improper Session Handling
 M7: Security Decisions Via Untrusted Inputs
 M8: Side Channel Data Leakage
 M9: Broken Cryptography
 M10: Sensitive Information Disclosure
 Top 10 Mobile Risks 2014-2015
 M1: Weak Server Side Controls
 M3: Insufficient Transport Layer Protection
 M4: Unintended Data Leakage
 M5: Poor Authorization and Authentication
 M6: Broken Cryptography
 M7: Client Side Injection
 M8: Security Decisions Via Untrusted Inputs
 M9: Improper Session Handling
 M10: Lack of Binary Protections
 Top 10 Mobile Risks 2016
 M1: Improper Platform Usage
 M3: Insecure Communication
 M4: Insecure Authentication
 M5: Insufficient Cryptography
 M6: Insecure Authorization
 M7: Client Code Quality
 M8: Code Tampering
 M9: Reverse Engineering
 M10: Extraneous Functionality
https://www.owasp.org/index.php/
Projects/OWASP_Mobile_Security_
Project_-_Top_Ten_Mobile_Risks
https://www.owasp.org/index.php/
Mobile_Top_10_2016-Top_10
Code Protection Code Protection &
Dev fails
Data Protection &
Dev fails

VULNERABILITIES IN DATA PROTECTION. EXCERPTs
Sensitive data leakage [CWE-200]
 Sensitive data leakage can be either inadvertent or side channel
 Protection can be poorly implemented exposing it:
Location; Owner ID info: name, number, device ID; Authentication credentials & tokens
Target App Information is also sensitive (out of scope of CWE-200)
Unsafe sensitive data storage [CWE-312]
 Sensitive data should always be stored encrypted so that attackers cannot simply retrieve this
data off the file system, especially on removable disk like micro SD card or public folders (out
of scope of CWE-312) such as
banking and payment system PIN numbers, credit card numbers, or online service passwords
 There’s no excuse for sandboxing without encryption here
Unsafe sensitive data transmission [CWE-319]
 Data be encrypted in transmission lest it be eavesdropped by attackers e.g. in public Wi-Fi
 If app implements SSL, it could fall victim to a downgrade attack degrading HTTPS to HTTP.
 Another way SSL could be compromised is if the app does not fail on invalid certificates.
 There’s no excuse for partial SSL validation here

SOLUTIONS

Vulnerability databases
Security scanners
Forensics software
Privacy Policy

SOLUTIONS. VULNERABILITY DBs
CVE, CWE, CVSS, NVD, and so on…
Put 100 vulns into the report – be ready to prove it works
Vulnerabilities are everywhere

SOLUTIONS. SECURITY SCANNERS
Incorporated into EMM, MDM, MAM solutions
Pure & High detailed at the same time
Based mainly on auto-scanners
Based on idea
API/System Calls  Data Item
That ≠ any info how’s protected
 Built like a checklist ‘be up-to-date’

SOLUTIONS. FORENSICS SOFTWARE
Isn’t easy to adopt for you needs.
You still don’t know how good or bad it was protected
But you know how much data can be extracted by these tools
Common features (example, Oxygen Software)
Social Networks. Extraction from Kate Mobile (30.1) from Android OS devices.
Messengers. Extraction from WhatsApp (2.16.1) including encrypted messages.
Messengers. Extraction from Skype (6.15.0.1162) from Blackberry 10 devices.
Business. Extraction from Yandex.Money (4.4.1) from iOS devices.
Messengers. Extraction from Telegram (3.7.0) from Android OS devices.
Messengers. Extraction from Viber (5.8.1) from iOS devices.
Social Networks. Extraction from LinkedIn (9.0.9) from iOS devices.
Social Networks. Extraction from Instagram (7.19.0) from Android OS devices.
http://www.oxygen-forensic.com/en/events/news

SOLUTIONS. PRIVACY POLICY
Privacy Policy is a ‘longread’ doc filled by scaring buzzphrases like:
We request all permissions & information we need
Do not guarantee the confidentiality of information and data
Participant is obliged to observe safety measures & care security
 Under no circumstances be liable of business interruption, loss of
business, or other data or information …
Certified by PCI DSS… and use SSL
Everything is 100% protected because of SSL
Keep yourself inform about security.. by yourself

SOLUTIONS. SUMMARY
• Vuln. DBs make sense for known vulnerabilities. Vuln. Scanner is like
• 1st day: “Device is not checked yet! Check now! Congrats – 100% Secure”
• 2nd day: “Oops, device is 50% protected”. Wait for developer’s update
• … 364th day: “Finally, updated. Now 86% protected”. Another app is bad. Wait for update
• Security Scanner is mainly based on app code scanner. Lack of useful details
• “This application has vulnerabilities”. See a section above (Vuln. DBs)
• “This application has a HTTP”. It’s bad app!
• “This application encrypt your traffic”. It’s good app!
• “This application request your Device ID, IMEI,… and ACCESS to FILE SYSTEM”
• Very detailed about device & lack of details about files? This is APIDATA
• “Device is jailbroken/rooted”. Don’t do that! Fix it!
• “Malware detected”. Remove it!

PANDA SM MANAGER IOS APP - MITM
SSL CERTIFICATE VULNERABILITY
 "Panda Systems Management is the new way to
manage and monitor IT systems.“
Issue
The Panda SM Manager iOS application (version 2.0.10
and below) does not validate the SSL certificate it receives
when connecting to a secure site.
http://osdir.com/ml/bugtraq.security/2016-
03/msg00018.html
Impact
An attacker who can perform a man in the middle attack
may present a bogus SSL certificate which the application
will accept silently.
Usernames, passwords and sensitive information could be
captured by an attacker without the user's knowledge.
Solution
Upgrade to version 2.6.0 or later
 Timeline
July 19, 2015 - Notified Panda Security via
security@xxxx, e-mail bounced
July 20, 2015 - Resent vulnerability report to
corporatesupport@xxxx & security@xxxx
July 20, 2015 - Panda Security responded stating they
will investigate
July 31, 2015 - Asked for an update on their
investigation
August 3, 2015 - Panda Security responded stating
that the issue has been escalated and is still being
reviewed
August 14, 2015 - Asked for an update on their
investigation
October 16, 2015 - Asked for an update on their
investigation
March 1, 2016 - Panda Security released version 2.6.0
which resolves this vulnerability
IT TOOK 6 MINOR RELEASES & 8 MONTHES TO FIX ‘MITM’ ISSUE

ANSWERS ARE LOOKING FOR?
What questions are usually asked by customers when they see a security report?
Which security holes are important and may lead to the leakage?
What data may leak through the particular hole?
Do updates help? And when it will be fixed?
At a customer level:
Doe app need access to emails in address book, or handles & display names?
Does browser process need access to the home directory, or just downloads directory?
What does media player need write access to?
Does any solution answer any questions? Not really.

UPDATES DON’T WORK!
o App v2
o SSL worked but MITM was
possible (preinstalled cert?)
o Privacy Policy
“We encrypt our services and data transmission
using SSL”
“You’re responsible for privacy”. Just do it yourself
On March, 2016
Slide #48, http://goo.gl/wPfmgM
o App v3
o Everything is in plaintext by
HTTP, even app installers (APK)
o Privacy Policy
We adopt appropriate data collection, storage and
processing practices and security measures to
protect against unauthorized access, alteration,
disclosure or destruction of your personal
information, username, password, transaction
information & data stored on Site
Official Website http://goo.gl/FYOXjE
MOBOMARKET (ANDROID APP STORE), BEST ONE IN CHINA & INDIA

UPDATES DON’T WORK!
o Before Summer/Autumn 2016
eFax
Media Data (faxes) are PINNED, but
Media URL of faxes, Credentials &
rest data are MITMed (Cert)
Evernote
Everything is PINNED, except
Social credentials of LinkedIn
Locally stored data
Accessible via iTunes incl. all DBs
o Since Autumn 2016
eFax
MITM with
preinstalled/crafted/stolen CERT
Applies to all data items
Evernote
Everything is MITMed with
preinstalled/crafted/stolen CERT
Location data is not protected
Documents & Location Info: GEO
Data & Address Data
eFax – weird SSL Pinning Evernote – downgraded from Pinning

COMPLEX DATA LEAKAGE
Don’t trust email
applications?
Signed up for
account on
popular services
and got a
confirmation
email?
Here we go!

UPDATES. IT WORKS!
OS updates / Vendors (Apple, Google, Asus, HTC,…)
App updates
Updates fix the issues sometimes
But keep an eye on a vendor activity

VKONTAKTE – iPHONE, iPAD, ANDROID
VK for iPhone/Android
 on fly MITM (no preinstalled cert need)
 HTTPS was turned off by default,
everything except credentials were
transferred by HTTP
 Updated in Autumn – now preinstalled
cert is need to MITM
VK for iPad
 on fly MITM (no preinstalled cert need),
https was turned off by default
June 5th, 2016
VK DBs records for just 1 Bitcoin
(approx. US$580)
VK.com HACKED! 100 Million Clear
Text Passwords Leaked Online
http://thehackernews.com/2016/06
/vk-com-data-breach.html

Apple iMessage EXPOSES USER IP
ADDRESS AND DEVICE DETAILS
 When the user opens iMessage to see the message,
even if he never clicks the link and accesses it,
iMessage would connect to the URL automatically,
and retrieve the necessary preview data plus user's
IP address, OS version, and device details.
 Preview & device data issue is not iMessage only
issue.
 Preview, device data and media have a weaker
protection issue is also known for many mobile apps
even if the rest data is good protected
http://news.softpedia.com/news/apple-s-
imessage-exposes-user-ip-address-and-device-
details-to-spammers-508948.shtml

APP IN THE AIR
Flight manager & notification app:
 In-App, SMS, stats, history, so on
Y2014: HTTP
 Simple notification app
Y2015+: HTTPS
 Fake/Crafted/Preinstalled certificate
to perform MITM

INSTAGRAM: FROM INSECURITY TO
INSECURITY THOUGHT THE SECURITY
Metadata is usually technical data that is associated with
User Content. For example, Metadata can describe how,
when and by whom a piece of User Content was collected
and how that content is formatted.
Users can add or may have Metadata added including
a hashtag (e.g., to mark keywords when you post a
photo),
geotag (e.g., to mark your location to a photo),
comments or other data.
It becomes searchable by meta if photo is made
public
Details: (1), (2)
https://goo.gl/1IxKUg https://goo.gl/LPh07C

INSTAGRAM: FROM INSECURITY TO
INSECURITY THOUGHT THE SECURITY
 Media Data incl. Advertisement and
Profile images
 Y2014: Media data transferred as is
without protection and hosted on Amazon
Storage Service (AWS S3)
 Y2015: Media data transferred over HTTPS
and hosted on Amazon Storage Service
(AWS S3); Crafted cert to MITM needed
 Y2016: Media data transferred as is
without protection and hosted on own
Instagram storages

PureVPN iOS V.1.0.2
PureVPN ANDROID V.5.4.0
Account Information
Account Details, Settings 'n' Configs, Credentials IDs+Passwords, Account Media, Tracked/Favorites
Analytics 'n' Ads Information
Analytics Configs, Device Data, Environment
Application Information
Application Certificates 'n' Profile + Configs, Credentials (IDs+Passwords+ Tokens)
Device Information
Device Data but network data is available by preinstalled certificate
Location 'n' Maps Information
GEO & Address Data
VPN Information
Application Configs
iOS App’s data items protected by SSL pinning_Android App’s data item MITMed by preinstalled certificate

CYBERGHOST iOS V.6.4
CYBERGHOST ANDROID V.5.5.1.7
Account Information
Account & License Details
Application Certificates 'n' Profile
Browser Information
Credentials IDs, Password, Tokens
Account & License Details, GEO Data, Environment, Application Config
Credentials Information
Credentials (IDs, Tokens, Access IDs, App Passwords, PreShared Secret)
Device Information
Environment & Network Details
GEO Data & Address Data
Log Information (supposed to be logs) – out of backup files, jailbreak/root required
Log Data, Credentials IDs, Tokens, Access IDs, App Passwords, PreShared Secret
GEO Data & Address Data, Account Details & License Details, Network Details
License information, credentials, app passwords, settings can be MITMed with crafted/stolen/installed certificate

iOS vs. ANDROID: CINEMAGIA
3.9.3 vs. 5.0.9 – Sept 2016
 iOS – MITM with preinstalled cert
Account Info
Booking 'n' Purchases Info
Credentials Info
Device Info
Location 'n' Maps Info
Payment 'n' Transaction Info
Social Info
 Android – Mainly w/o protection
Account Info
Booking 'n' Purchases Info
Credentials Info
Device Information
Location 'n' Maps Info
Payment 'n' Transaction Info
Social Info

GHOST PROJECTS: MOBILE APPS ALIVE, BUT NO
CHANGES SINCE MAY Y2014
ALTERGEO iOS 4.6 / Android 3.13
Account Information: Account Details, GEO & Address Data
Contact Information: Profile, Social, GEO, Stream, Place Details, Media URLs
Analytics 'n' Ads Information: Device Data & Environment
Browser Information: Credentials IDs, Passwords, Tokens
Credentials Information: Credentials IDs, Passwords, Tokens
Location Info: Messages, GEO & Address Data, Place Details, Media Data
Loyalty Information: GEO & Address Data + Place Details
Media Information: Place Details
Social Information: Media Data, Stream, Place Details + GEO Data
Out of backup file (rest is in backup)
Account Information: Address Data
Contact Information: Media Data
Location Info: GEO & Address Data, Place Details, Media Data
AlterGeo is Russian clone of Foursquare & Swarm; nothing is protected except browser log-in, but not an in-app login

WEIRD PROJECTS:
WEATHER STREET STYLE 1.8.6
ANDROID ONLY
Account Information
Account & Media Data
Address Data, Account Settings
Credentials IDs + Passwords
Activation IDs + Tokens
Device Information:
Device Details
Location 'n' Maps Information:
GEO Data, GEO Snapshots
Social Information:
Contact Profile, Media Data, Messages
Weather Information:
Weather Data
Weather style is app to show what people wear at the moment in different countries. Everything in plaintext

IHG & MARRIOTT APPS
WHEN ENCRYPTION DOESN’T MATTER
Everything is MITMed with crafted / stolen / preinstalled certificate
Account, Analytics, Application Info, Booking, Credentials, Device Information,
Financial Information, Location, Log, Loyalty, Media, Payment 'n' Transaction,
Personal 'n' Private and Travel Information
Encrypted Credentials Information: Passwords - IHG only
Doesn’t make a sense if it’s only way to give an access to the user account
Makes a sense if it’s data that stored locally if it’s out of backup even
Limited access by a time (no longer 180 days)
Booking 'n' Purchases Information: Orders & Reservation History

FLOW & IFTTT
ABSOLUTE POWER OVER YOUR ACCOUNTS 
In this research were found over 8K data items
30 unique data groups
105 unique data items
462 unique pairs of data group & data item
In each app Flow and IFTTT were found
15 unique data group out of all 30 = 50%
52 unique data items out of all 105 = 50%
~150 unique pairs of data group & data item out of all 462 = 30%
Everything is MITMed with crafted / stolen / preinstalled certificate
Account, Analytics, Browser, Credentials, Device Info, Events, Location,
Media, Message, News, Social, Storage Info, Tasks, Weather, Workflow
Data includes everything to direct access, such as credentials/tokens, and data
itself from linked services, such as Dropbox or mobile device GEO/network lists
IFTTT & Flow are two apps to automatize any kind of activities with social networks or IoT

WECHAT
HOW TO FAIL BEING AWESOME
Awesome protected (many security fails fixed by now), encrypted, own
protocol:
Account Information: Account Settings 'n' Configs
Address Book 'n' Contact Information: Contact Profile
Application Information: Application Configs
Location 'n' Maps Information: GEO Data
Message Information: Media Data, vCard, Messages, Short Profile
But Location data is still out of protection
Location 'n' Maps Information: Contact Media
Message Information: GEO & Address Data, GEO Snapshots, Place
Details
Many Chinese apps might be with a lack of protection or overloaded with own protocols, encryption of data and code

FACEBOOK & MESSENGER.
DUPLICATE DATA, PREVIEW AND LOCATION FAILS
Log Data
Credentials (Passwords)
Credentials (App Passwords)
Transaction History
Contact Short Profile
Credentials (IDs)
Card Full Information
Card Short Information
Credentials (Tokens)
Browser Information
Preview
Message Information
GEO Data
GEO Snapshots
https://m.facebook.com/password/change/?refid=70

EMAIL APPS – MESSAGES MIGHT BE PROTECTED
Gmail – N#4, L#0 Account data & media URLs, Settings + profile, Rest L#6
Yandex.Mail – Messages N#6, rest N#4, App Configs & Account settings – L#0, Rest L#6
MailTime – Message & Sender Info – N#7, Rest N#4 (iOS) or N#6 (Android), L#0
Mail.Ru – N#4, L#6 – Creds, Message Attachs & Sender Info, rest L#0
MyMail – N#4, L#6 – Creds, Message Attachs & Sender Info, rest L#0
YahooMail – N#4, L#6 – Creds, AddressBook & Media, Log & App Events
Newton Mail (prev. CloudMagic) – N#4, L#0 – Creds & Device Data, rest L#6
MS Outlook – Credentials – N#4, rest N#7, Attach & Sync Docs – L#6, rest L#0
Alto – N#4, Creds - Config, Analytics, Logs, Creds, Attachs – L#6, rest L#0
N#7 - Non-standard protocol
N#6 - Pinned cert
N#4 - Intercept/MITM with preinstalled/crafted cert
N#2 – MITM on fly without preinstalled trusted cert
L#6 – out of backup file
L#0 – in backup

TAXI APPS – EVEN PAYMENTS MIGHT NOT BE PROTECTED
Meridian – Social Account, Geo & Creds N#4, rest N#0, L#0
Taxi 777 – Device & Environment Analytics N#4, rest N#0, L#0
Fixtaxi (Aerotaxi) – N#0, L#0
Gett (Gettaxi) – N#4, L#0
CleverTaxi – N#4, L#0
CrisTaxi – Social Account, Geo & Creds N#4, rest N#0, L#0
YandexTaxi – Activation Code N#6, Creds, Geo & Address - N#5,
rest – Bank Card, Orders, Favorites N#4, L#0
N#6 - Pinned cert
N#5 – same as N#4 but pinning inform about weird cert
N#0 – No Protection
L#0 – in backup

WALLET APPS – PROTECT SYNC DATA ONLY
NS Wallet (any edition) – Device Data N#4, In-App iOS Payment N#6, Creds Sync Data
L#8, rest L#0
EnPass – Creds Sync Data N#8, rest incl. Creds N#4, Creds Sync Data L#8, rest L#0
Dashlane – Creds Sync Data N#8, rest incl. Creds, app config, logs… N#4, Creds Sync
Data L#8, rest L#0
LastPass – Creds Sync Data N#8, rest incl. Creds, app config, device info… N#4, Creds
Sync Data L#8, rest L#0
Sticky Password – Creds Sync Data N#8, rest incl. Creds, License Details N#4, Creds
Sync Data L#8, rest L#0
1Password – Creds Sync Data N#8, rest incl. Creds, app config, device info… N#4,
Creds Sync Data L#8, rest L#0
N#8 – Encrypted
N#6 - Pinned cert
L#0 – in backup

MEDIA AND LOCATION LEAKS.
NO PROTECTION
• Account Data
• Address Data
• Contact Media
• GEO Data
• GEO Snapshots
• Maps Data
• Media Data
• Messages (Comment on
• Personalization
• Place Details
• Tracked Data 'n' Favourites
• AlterGeo
• Aviasales
• Booking.com
• Cris Taxi Bucuresti
• Evernote
• Fixtaxi (Aerotaxi)
• Foursquare
• Instagram
• Marriott
• Meridian Taxi
• momondo
• Plazius
• Skyscanner
• Taxi 777
• Velobike
• VK for iPad
• Weather Street Style
• WeChat

SENSITIVE DATA. NO PROTECTION
• Aeroexpress
• AlterGeo
• Anywayanyday
• AppCompass
• Aviasales
• Booking.com
• British Airways
• Cinemagia
• Cris Taxi Bucuresti
• Evernote
• Facebook
Messenger
• Fixtaxi (Aerotaxi)
• Flipboard
• Fly Delta
• Foursquare
• IHG
• Instagram
• KliChat
• Lookout
• Marriott
• Meridian Taxi
• Microsoft Office
• momondo
• OK Messages
• Pinterest
• Plazius
• Skyscanner
• Swarm
• Taxi 777
• Velobike
• VK
• Weather Street Style
• WeChat
• Account Details
• Account Settings 'n' Configs
• Address Data
• Application Configs
• Card Full Information
• Contact GEO, Media, Profile
• Credentials (IDs, Passwords, Tokens)
• Device Details, Environment
• Messages
• Orders & Reservation
• Passport Data (Short)
• Personalization
• Place Details
• Preview
• Stream
• Tracked Data 'n' Favourites
• Travel Details

UNTRUSTED PLACES
• Untrusted chargeable places.
• When you connect your device to them you will see a notification
you plugged to PC/Mac
• Or lost devices
• Untrusted network places.
• When you connect your device to them
• You will see nothing
• You will see a question about untrusted certificate. You accept or
decline it
• Someone make you to install trusted certificate

EXTRACTING LOCAL DATA. EXAMPLES
• Oxygen Forensic® Detective introduces offline maps and new
physical approach for Samsung Android devices!
• The updated version offers a new physical method for
Samsung Android OS devices via custom forensic recovery. This
innovative approach allows to bypass screen lock and extract
a full physical image of supported Samsung devices.
• http://www.oxygen-forensic.com/en/events/news/666-
oxygen-forensic-detective-introduces-offline-maps-and-new-
physical-approach-for-samsung-android-devices

DefCamp_2016_Chemerkin_Yury_--_publish.pdf

SSL ISSUES: Apps, Mozilla, WoSign,
Apple, Google
Applications handle SSL connection in different ways:
Some don’t validate SSL certificate during the connection
Many trust to the root SSL certificates installed on the device due to SSL validating
Some have pinned SSL certificate and trust it only
Trusting root certificate might not be a good idea (Mozilla reports):
Between 16th January 2015 and 5th March 2015, WoSign issued 1,132 SHA-1 certificates
whose validity extended beyond 1st January 2017
Between 9th April 2015 and 14th April 2015, WoSign issued 392 certificates with duplicate
serial numbers, across a handful of different serial numbers
It is important background information to know which WoSign roots are cross-signed by
other trusted or previously-trusted roots (expired but still unrevoked)
Eventually Apple removes SSL certificate from iOS, perhaps from iOS 10 only
https://support.apple.com/en-us/HT204132, https://support.apple.com/en-us/HT202858
https://threatpost.com/google-to-distrust-wosign-startcom-certs-in-2017/121709/

DATA PROTECTION CONCEPTS (DPC)
There are known many of them, some were renamed but still 3:
Data-at-Rest (DAR)
Locally stored data on internet or external storage. Data might divide
into several parts, full data, backup data, and containerized data
Data-in-Transit (DIT)
Data transmitted over Internet and local wireless network (as part of
solid internet connection) and limited by it
Data-in-Use (DIU)
Referred to data operated in internal memory (not storage) and
application code, like hardcoded values

IMPLEMENTATION OF DPC. DATA-AT-REST
 No special tools for viewing various data types
 No root to gain an access backup data
 No root to gain an access to internal storage to
the application data folder (works only for iOS
older than 8.3) CVE-2015-1087
 Root to gain an access to internal storage to the
keychain folder
 Root to gain an access to internal storage to the
application data folder (iOS 8.3 and higher)
 Root to gain an access to internal storage in
general
 No special tools for viewing various data types
 Root to gain an access to internal storage.
 No root to gain an access to external storage,
public folders or backup data
 Unlocking locked bootloader wipes all data on
several devices, e.g. HTC
 Non-locked or unlocked bootloader might give an
opportunity to root a device, grab data or install
malicious application and de-root it back, e.g.
Samsung, LG (details, news, http://www.oxygen-
forensic.com/en/events/news)

IMPLEMENTATION OF DPC. DATA-IN-TRANSIT
Do not require a root for cases, such as
onon-protected traffic,
ono SSL validation except centralized list of certificates
oMITM possible - fake/crafted/stolen SSL certificate installed as trusted
Require root for cases, such as
oSSL Pinning to bypass it automatically or manually
oRest cases that directly impacts on app code and mixed with DIU
 App-level proxy
is an alternative internet access
 OS-level proxy
 no app-level alternative tunnels

QUANTIFICATION SECURITY LEVELS. DAR
Non-Protected
Protection N/A or Jailbroken iOS
Encode Protected
Encoded data (zlib, bas64, etc.)
Weak Protected
App Data access w/o jailbreak iOS <8.3
Obesity Protected
Not Defined
Medium Protected
Data available via sharing, such as iTunes
Iterim Protected
Access limited by time, e.g. cache folders
Good Protected
Not Defined
Strong Protected
Sandboxed data, jailbreak needs & wipe data
Extra Protected
No public tools for a jailbreak is available
Best Protected
Not Defined
Protection N/A, rooted,public folders,SD cards
Encoded data (zlib, bas64, etc.)
Not Defined
Not Defined
Not Defined
Access limited by time, e.g. cache folders
Sandbox, root/unlocking not wipe data
Sandboxed data, root needs & wipe data
No public tools for a jailbreak is available
Not Defined

Non-Protected
Protection N/A, Jailbroken, crafted certificate Protection N/A, rooted, crafted certificate
Encode Protected
Encoded data (zlib, bas64, etc.) Encoded data (zlib, bas64, etc.)
Weak Protected
Stolen or expired certificates Stolen or expired certificates
Obesity Protected
Not Defined Not defined
Medium Protected
Basic feature of SSL validation of certificates Basic feature of SSL validation of certificates
Iterim Protected
Not defined App-level proxy/tunnel for internet
Good Protected
Not defined Not defined
Strong Protected
Not defined Not defined
Extra Protected
System and/or user VPN System and/or user VPN
Best Protected
Not Defined Not defined
QUANTIFICATION SECURITY LEVELS. DIT

LIST OF SOFTWARE RELATED TO
SECURITY CHECKS
File Viewers
Online services & tools for calculations
Network Debug & Pentest
Debuggers, Disassemblers, Decompilers,
activity tracers, and pentest frameworks
File & Device Access
Forensics & special pentest solutions
No tools
Non-Protected
Weak Protected
Obesity Protected
Medium Protected
Iterim Protected
Good Protected
Strong Protected
Extra Protected
Best Protected
Encode Protected
Free or
paid
$100-
300 or
less
Free or Paid
Home ~$100
Enterprise
$300+
$5-10k+,
lightweight -
$100-1k
No tools, if no
data available

SOLUTIONS: FOR DEVELOPERS
 Secure Mobile Development Guide by NowSecure
 Coding Practices
 Handling Sensitive Data
 iOS & Android Tips
 etc.
 https://books.nowsecure.com/secure-mobile-
development/en/index.html

SOLUTIONS: DATA PROTECTION DBs
• We [as security experts] know what data is protected and not
protected despite of it’s locally stored, transferred or hardcoded
• Also, we know two simple things
• not only users publish their data
• developers can’t protect data
• At the same time we’re customers, right?
• I’m as a customer prefer and have a right to know where devices shouldn’t
be connected to network or plugged PC/Mac.
• Developers aren’t going to tell me if they fail. Instead they’re telling
‘everything is OK but they're not responsible for anything’

SOLUTIONS: DATA PROTECTION DBs
• Goal is providing a solution that helps to keep ‘everyone’
informed about app security fails.
• Everyone means
• app users as well as app developers
• you don’t need to be expert to understand that how it affects
you; you just know if it has required level of protected or not
• but you have to get used that your application operates many
data visible and not visible for you beyond the blueberry
muffins over the weekend

Vulnerabilities matter but exist over 40 years
Vulnerability is a defect/flaw in design in dev’s code or third party libraries
Lack of data protection is usually an insecurity by design and implementation fails
Even OWASP considers data protection as more important thing than vulnerabilities by now
Lack of data protection is described by 3 vulnerabilities
sensitive data leakage, storage, transmission CWE-200, CWE-312, CWE-319
PrivacyMeter gives answer about (at the moment)
list of apps and average values (Raw value, Environment value depend on OS)
list of app data items grouped by ‘protection levels/categories’
data item protection level and explanation
examination of privacy policy in regards to gained app results
Results are available on the web-site http://www.privacymeter.online/ see booklets (!)
Download the Autumn Report http://www.privacymeter.online/reports see booklets (!)

APPS FINDINGS. OVERALL RESULTS
250 apps = 135 iOS apps + 115 Android apps
8124 data items = 4287 (iOS) + 3837 (Android)
20+ application groups (17 unique groups)
30 data groups & 105 data items over 8K data items
462 unique pairs of data group & data item
News & Magazines
Productivity
Shopping
Social Networking
Tools & Utilities
Transportation
Travel & Local
Weather
Business
Communication
Entertainment
Finance
Food & Drink
Lifestyle
Photo & Video
Music
Navigation

DATA GROUPS' AVERAGE PROTECTION
LEVEL. iOS VS. ANDROID
0.00 1.00 2.00 3.00 4.00 5.00 6.00 7.00
Account Information
Address Book 'n' Contact Information
Application BaaS Information
Booking 'n' Purchases Information
Bookmark Information
Browser Information
Call Information
Device Information
Documents Information
Events Information
Financial Information
Log Information
Loyalty Information
Media Information
Message Information
News Information
Notification Information
Payment 'n' Transaction Information
Personal 'n' Private Information
Social Information
Storage Information
Tasks Information
Travel Information
Visa 'n' Passport Information
VPN Information
Weather Information
Workflow Information
iOS Android

QUANTITY OF APPS PER EACH GROUP
0.00%
10.00%
20.00%
30.00%
40.00%
50.00%
60.00%
70.00%
80.00%
90.00%
100.00%
Worst applications Bad applications Good applications Best applications
iOS 27.41% 100.00% 97.04% 30.37%
Android 24.35% 100.00% 30.43% 20.87%
27.41%
100.00% 97.04%
30.37%
24.35%
100.00%
30.43%
20.87%
iOS Android

WORST PROTECTED ITEMS OVER APPS
0
1
2
3
4
5
6
Env (iOS) Raw (iOS) Env (Android) Raw (Android)

WORST PROTECTED ITEMS OVER APPS
 Account Information: Account Details, GEO & Address
 Contact Information: GEO + Profile + Social + Media URLs + Place Details +
Stream
 Analytics 'n' Ads Information: Device Data & Environment
 Credentials Information: Credentials IDs & Passwords
 Events Information: Stream
 Location 'n' Maps Information: GEO & Address, Media Data, Messages, Place
Details
 Loyalty Information: Account Data, GEO & Address, Place Details
 Media Information: Place Details
Many of applications reveal something in plaintext 8 groups, 16 data items, 30 pairs of group + data items

WORST iOS AND ANDROID APPLICATIONS
0
0.5
1
1.5
2
2.5
3
AppCompass Cris Taxi
Bucuresti
Fixtaxi
(Aerotaxi)
Meridian Taxi Skyscanner Taxi 777 Velobike

GOOD iOS & ANDROID APPS
0
1
2
3
4
5
6
4.6
4.8
5
5.2
5.4
5.6
5.8
Asana British
Airways
British
Airways for
iPad
Cloud Hub Firefox Google
Trips
NS Wallet
FREE
NS Wallet
PRO
ParkSeason Spaces Trello

http://goo.gl/9WF2dC http://goo.gl/CT4nTT
RISKWARE BETRAYER. TWO POLLS

[ YURY CHEMERKIN ]
• MULTISKILLED SECURITY EXPERT
• EXPERIENCED IN :
• REVERSE ENGINEERING & AV, DEVELOPMENT (PAST)
• MOBILE SECURITY, & CLOUD SECURITY
• IAM, COMPLIANCE, FORENSICS
• PARTICIPATION & SPEAKING AT MANY SECURITY
CONFERENCES

RISKWARE BETRAYER
WHO IS THE BIGGEST ONE?
HOW TO CONTACT ME ?
ADD ME IN LINKEDIN:
HTTPS://WWW.LINKEDIN.COM/IN/YURYCHEMERKIN
YURY CHEMERKIN
SEND A MAIL TO: YURY.S@CHEMERKIN.COM

DefCamp_2016_Chemerkin_Yury_--_publish.pdf

Related slideshows

More Related Content

Similar to DefCamp_2016_Chemerkin_Yury_--_publish.pdf

Similar to DefCamp_2016_Chemerkin_Yury_--_publish.pdf (20)

More from Yury Chemerkin

More from Yury Chemerkin (20)

Recently uploaded

Recently uploaded (20)

DefCamp_2016_Chemerkin_Yury_--_publish.pdf
