Unit-IV Gate Level Design: Switch logic, Pass
transistors, transmission gates alternate gate circuits,
Pseudo- NMOS logic, Differential Cascaded Voltage
Static logic (DCVS) logic, Dynamic logic, Domino
logic, Clocked CMOS logic, Low power gates.

Subsystem Design
(Guide Lines to be Followed)

Take, for example, the case of a relatively
straightforward MSI logic circuit comprising, say, 500
transistors. A reasonable time to allocate to the design
and proving of such a circuit could be some two
engineer months.
Consider now the design of a 500,000 transistor VLSI
system. Even if a linear relationship exists between
complexity and design time, the required design time
would be 2000 engineer-months or 170 engineer-years.

1. Define the requirements (properly and carefully).
2. Partition the overall architecture into appropriate
subsystems.
3. Consider communication paths carefully in order to
develop sensible interrelationships between subsystems.
4. Draw a floor plan of how the system is to map onto
the silicon (and alternate between 2, 3 and 4 as
necessary).

5. Aim for regular structures so that design is largely
a matter of replication.
6. Draw suitable (stick or symbolic) diagrams of the
leaf-cells of the subsystems.
7. Convert each cell to a layout.
8. Carefully and thoroughly carry out a design rule
check on each cell.
9. Simulate the performance of each cell/subsystem.

Switch logic is based on the 'pass transistor' or on
transmission gates. This approach is fast for small
arrays and takes no static current from the supply rails.
Thus, power dissipation of such arrays is small since
current only flows on switching.

Switch (pass transistor) logic is similar to logic
arrays based on relay contacts in that the path
through each switch is isolated from the signal
activating the switch. In consequence, the designer
has a considerable amount of freedom in
implementing architectural features compared with
bipolar logic-based designs.

n-MOS transistor/ switch produces Strong ‘0’
but weak ‘1’

p-MOS transistor/ switch produces Strong ‘1’
but weak ‘0’

Transmission gate produces Strong
both strong‘1’ and strong ‘0’.

2 Input NAND GATE (using n-MOS & CMOS Logic)

 Pseudo- NMOS logic
 Dynamic logic
 Domino logic
 Clocked CMOS logic
 Differential Cascaded Voltage Static logic (DCVS)
logic

Clearly, if we replace the depletion mode pull-up
transistor of the standard nMOS circuits with a p-
transistor with gate connected to Vss, we have a
structure similar to the nMOS equivalent.
1.Power dissipation is reduced to about 60% of that
associated with the comparable nMOS device.
2. Owing to the higher pull-up resistance, the inverter
pair delay is larger by a factor of 8.5:5 than the 4:1
minimum size nMOS inverter.

Dynamic CMOS logic
Φ=0, pre charge stage
Φ=1, evaluation stage
3 Input NAND GATE

The actual logic is implemented in the inherently faster
nMOS logic (the n-block); a p-transistor is used for the
non-time-critical precharging of the output line 'Z' so that
the output capacitance is charged to V DD during the off
period of the clock signal .
During this same period the inputs are applied to the n-
block and the state of the logic is then evaluated during
the on period of the clock when the bottom n-transistor is
turned on.

The output voltage level is stored in a capacitor during the
precharge phase of the clock cycle, and then evaluated
during the evaluation phase. Dynamic CMOS logic has
high speed, low area, and simple layout. However, it also
has some challenges, such as high power dissipation, low
noise margin, and low fan-out.

Advantages of Clocked CMOS Logic
 Predictable Timing
 Simplified Sequential Design
 Ease of Design and Debugging
 Improved Signal Integrity
Disadvantages of Clocked CMOS Logic
 Increased Power Consumption
 Clock Skew and Jitter
 Area Overhead
 Latency
 Design Complexity

1. Such logic structures can have smaller areas than
conventional CMOS logic.
2. Parasitic capacitances are smaller so that higher
operating speeds are possible.
3. Operation is free of glitches since each gate can make
only one '1' to '0' transition.
4. Only non-inverting structures are possible because of
the presence of the inverting buffer.
5. Charge distribution may be a problem and must be
considered.

DCVS Logic
• DCVS - Differential
Cascode Voltage
Switch
• Differential inputs,
outputs
• Two pulldown networks
• Tradeoffs
– Lower capacitative
loading than static
CMOS
– No ratioed logic
needed
– Low static
power
consumption
– More transistors
– More signals to route
between gates
OUT
Pulldown
Network
OUT’
OUT’
Pulldown
Network
OUT
A
B
C
A’
B’
C’

DCVS logic:
BAR
AB
Y 
AB
Y 

Advantages of DCVS Logic
•High-Speed Operation
•Low Power Consumption
•Reduced Noise Sensitivity
•Better Signal Integrity
Disadvantages of DCVS Logic
Increased Complexity
Design complexity/Area overhead

Introduction
 Definition: What are low power gates?
 Importance: Why is low power design crucial in
modern electronics?
Power Consumption in Digital Circuits
 Dynamic Power Consumption: Switching activity,
capacitive load
 Static Power Consumption: Leakage currents,
subthreshold leakage

Techniques for Low Power Design
 Voltage Scaling: Lowering supply voltage
 Clock Gating: Reducing clock signal to idle portions
of the circuit
 Power Gating: Shutting off power to inactive blocks
 Multi-Threshold CMOS (MTCMOS): Using
transistors with different threshold voltage

Types of Low Power Gates
 Standard CMOS Gates: Basic CMOS inverter,
NAND, NOR
 Sub-threshold Gates: Operating at voltages below
the threshold voltage
 Adiabatic Logic Gates: Energy recovery logic
 FinFET Technology: Reducing leakage current
and dynamic power

A FinFET is a type of field-effect transistor (FET) that
has a thin vertical fin instead of being completely
planar. The gate is fully “wrapped” around the
channel on three sides formed between the source and
the drain.

Planar transistors vs. finFETs vs. gate-all-around Source: Lam
Research
