stackconf 2024 | Ignite: Distributed Tracing using OpenTelemetry and Jaeger by AJ Jester.pdf
- 1. 1 Distributed Tracing using OpenTelemetry and Jaeger 1 Prepared by: AJ
- 2. 2 2 ● Several years ago when you had a monolithic application, it was fairly easy to debug and diagnose since there was probably only one service with a couple of users. ● Nowadays systems are broken up into smaller microservices deployed in containers on top of Kubernetes in multiple clusters across different cloud environments. ● In these kinds of distributed environments, there is a need to observe it all, both the overall picture, and, if need be, at a more granular level.
- 3. 3 3 ● Observability can be roughly divided into three sub-categories: logging, metrics, and tracing. ● Tracing is the term used to describe the activity of recording and observing requests made by an application, and how those requests propagate through a system. ● When systems are set up in a distributed fashion, we call this distributed tracing as it involves observing the application and its interactions through multiple systems. ● For example, as a developer your code probably includes multiple functions, but you are more interested in how long the functions take to execute and the interdependency of those functions as they are used in the application.
- 4. 4 4 Tracing will give the necessary insights by ● Identifying performance and latency bottlenecks ● Finding root cause analysis after major incidents ● Determining dependencies in multi-service architecture ● Monitoring transactions within your application
- 5. 5 5 ● Let’s start by taking a look where it makes sense to add tracing. ● Here we’ll get started with a small Python application that will show a couple of simple operations. ● We’ll then later add the code for tracing to measure the time it takes for our code to execute.
- 6. 6 6 Initially the code would look something like this minio_client.fput_object(config["dest_bucket"], file_path, file_path)
- 7. 7 7
- 8. 8 8 Install OpenTelemetry… $ pip install opentelemetry-api $ pip install opentelemetry-sdk and import Trace from opentelemetry import trace
- 9. 9 9 Initialize the trace… resource = Resource(attributes={ SERVICE_NAME: "my-minio" }) provider = TracerProvider(resource=resource) processor = BatchSpanProcessor(ConsoleSpanExporter()) provider.add_span_processor(processor) trace.set_tracer_provider(provider) tracer = trace.get_tracer(__name__) and create a Span with tracer.start_as_current_span("check if bucket exist"):
- 10. 10 10 You can create additional multiple spans with tracer.start_as_current_span("create object to add"): with tracer.start_as_current_span("add created object to bucket"): with tracer.start_as_current_span("fetch object from bucket"): with tracer.start_as_current_span("remove object from bucket"): with tracer.start_as_current_span("check if bucket exists"):
- 11. 11 11 Once a span is created you can add custom attributes ● Adding a function name current_span.set_attribute("function.name", "CHECK_BUCKET") ● Adding a Span event current_span.add_event("Checking if bucket exists.") if not minio_client.bucket_exists(config["dest_bucket"]): current_span.add_event("Bucket does not exist, going to create it.") minio_client.make_bucket(config["dest_bucket"])
- 12. 12 12 You can create multiple span events current_span.add_event("Test object has been placed in bucket.") current_span.add_event("Test object has been fetched from bucket.") current_span.add_event("Test object has been removed from bucket.") current_span.add_event("Bucket exists, going to remove it.")
- 13. 13 13 Configuring Jaeger ● Install Jaeger package pip install opentelemetry-exporter-jaeger ● Import and Configure Jaeger from opentelemetry.exporter.jaeger.thrift import JaegerExporter jaeger_exporter = JaegerExporter( agent_host_name="localhost", agent_port=6831, )
- 14. 14 14 Go to http://localhost:16686/ to access the Jaeger UI
- 15. 15 15 Using Jaeger UI find the traces
- 16. 16 16 So far we’ve only made one request, and there should be a couple of traces from the few spans we created.
- 17. 17 17 Click on one of the traces which shows 2 Spans; let's choose the one that says “check if bucket exists”.
- 18. 18 18 After running the script five to six times, we can start to see patterns emerge.
- 19. 19 19 Is tracing the only option? ● Tracing is just one of the pieces in the path towards observability. ● Generally when incidents happen it's not just one trace or one log or one metric that we use to determine and resolve the issue. ● Often it is understanding the combination of these things that is required to get to the root cause.
